Power Supply

Voltage: AC95V - 240 v, 50 -60 hz

Power: 400 w

Electronic ballast and AC/DC switching power supply. Power factor is as high as 0.99, THD < 20%.

Support power adjustment bulb, bulb power consumption reduced by 50%, extend the lamp life,

High stability of lamps and lanterns

Light Source

Bulb specifications: Philips MSD Platinum 330 w

Lamp life: 2000 hours

Typical lumen maintenance ratio: % @ 70 2000 hours

Color temperature: 8000, white light color temperature adjustable function, luminous flux is 7950 lm

Operation

DMX channels: 16 DMX channels

Control mode: Master-Slave/Sound Activated/Stand-Alone & Auto mode

Design & color

Gobo :11gobos+white double rotation rainbow effect shake function

Colors :14 color+white,single rotation rainbow effect, two models changing(Full color and half color operating)

 With color offset adjustment function,With Hall location function

Prism: 8 Prism Rotation , positive and negative direction of rotation can be accurate positioning function

The Angle

Rotation Angle: horizontal vertical direction of 540 ° 540 °

Horizontal vertical, horizontal and vertical used three-phase motor driver, horizontal vertical scanning 270 ° 540 °,

Has 8 bit and 16 bit scanning precision, can be confirmed along the semen leakage, and can adjust the speed of scanning

beam Angle: 4 °

The optical system

Atomization: 0 ~ 100 linear atomization effect

Stroboscopic: frequency can reach 1 ~ 14 times per second, adjustable frequency stroboscopic effect

Linear dimming: 1% ~ 1% dimmer

Focus: high quality projection lens, with the function of focusing

Safety and appearance

Working environment: indoor, 0 ℃ to 40 ℃

Product size: 560×520×580mm

Packing size: 590×540×620mm

N.W: 20 Kg
