Light source: Philips 130w
Pan 540° / Tilt 270°
Beam Angel: 0 °- 3.2 °
Standard DMX512 control mode
Channel: 16 DMX channels
Gobo :14 gobos+white
Color: 13 color + white color plate
Dimming: 1 ~ 100% linear dimming function
Power supply
Voltage:90V-240V AC,50/60HZ
Power:180W
Rectifier: electronic rectifier power factor as high as 0.99, THD < 20 ‰, supporting the lamp
Bubble power adjustment, bulb power consumption reduced by 50%, improve the stability of lamps and lanterns
Light source
Bulb specifications: Philips 130w
Color temperature: luminous flux is 3970 m, the color WenKeDa 8300 k
Operation
DMX channels: 16 DMX channels
Control mode: Master-Slave/Sound Activated/Stand-Alone & Auto mode
Design & color
Gobo :14 gobos+white double rotation rainbow effect shake function
Colors :13 color+white,single rotation rainbow effect, two models changing(Full color and half color operating)
With color offset adjustment function,With Hall location function
Prism:8 Prism Rotation , the positive and negative direction of rotation can be precise positioning function atomization: 0 ~ 100% linear atomization effect
The Angle
Scanning: used three-phase motor drive, the horizontal and vertical horizontal rotation Angle 450 ° vertically
Rotation Angle 270 °, with 8 bits and the scanning precision of 16 bits, can arrange semen leakage field
, and can adjust the speed of rotation
Focus: high quality projection lens, with the function of focusing
Beam Angle: effect of small Angle beam, beam Angle of 0 ~ 3.2 degrees
The optical system
Focus: high quality projection lens, with the function of focusing
The dimming: 1 ~ 100% linear dimming function
Stroboscopic: high precision electric adjusting side knife stroboscopic highest frequency can be 13 times per second
And you can choose random stroboscopic and pulse frequency flash
Safety and appearance
Appearance: small size and light weight high strength heat-resistant engineering plastics shell, sleek design
Working environment: - 20 °C-40 °C
Protection grade: IP20
Product size: 337 * 302 * 471 mm
Packing size: 545 * 430 * 390 mm (carton)
N.W: 17.8 Kg
G.W: 20.5 Kg (carton)
