Product model: DY-MH010
Product name: 10R 280W Beam Moving Head Light
Product parameters:
Beam Spost Wash
Lamp: Osram HRI 280W
Control channels: 24Chs & 16Chs
Lamp: Osram HRI 280W
Control channels: 24Chs & 16Chs
Parameter
Pattern color
Product effect
Data download
Input voltage : 100–240 V, 50/60 Hz
Lamp: Osram HRI 280W
Color temperature: 9300K
Power consumption: 480W
Zoom : Beam mode:2.5°-10° / Spot mode :5° – 20°
Colour wheel: 13 dichroic filters + white
Rotate Gobo wheel: 9 rotating, indexable and replaceable
Static Gobo wheel: 14 gobos + open
Prism 1: 8-prism
Prism 2: 6-prism
Frost effect: Separate, variable
Dimmer/Shutter: Full range dimming and variable strobe effect
Pan: 540°
Tilt: 270°
Control channels: 24Chs & 16Chs
Control mode : Standard DMX512, Automatic and Master/ slave mode
Frost: 8 bit
Zoom: 8 or 16bit
Focus: 8 or 16bit
Dimmer: 8 or 16bit
Data in/out: 3-pin & 5-pin XLR
Dimensions: 59*37*39 CM
Weight: 21KG
Lamp: Osram HRI 280W
Color temperature: 9300K
Power consumption: 480W
Zoom : Beam mode:2.5°-10° / Spot mode :5° – 20°
Colour wheel: 13 dichroic filters + white
Rotate Gobo wheel: 9 rotating, indexable and replaceable
Static Gobo wheel: 14 gobos + open
Prism 1: 8-prism
Prism 2: 6-prism
Frost effect: Separate, variable
Dimmer/Shutter: Full range dimming and variable strobe effect
Pan: 540°
Tilt: 270°
Control channels: 24Chs & 16Chs
Control mode : Standard DMX512, Automatic and Master/ slave mode
Frost: 8 bit
Zoom: 8 or 16bit
Focus: 8 or 16bit
Dimmer: 8 or 16bit
Data in/out: 3-pin & 5-pin XLR
Dimensions: 59*37*39 CM
Weight: 21KG
